Filling Equipment - - GLZON
| Model | 320VFFS | 420VFFS | 520VFFS | 620VFFS | 720VFFS |
| Packing Speed | 10-80p/M | 10-70p/M | 10-60p/M | 10-50p/M | 10-45p/M |
| Bag Size | 50-200mm(L)*60-150mm(W) | 60-300mm(L)*60-200mm(W) | 50-350mm(L)*50-250mm(W) | 20-400mm(L)*100-300mm(W) | 20-450mm(L)*140-350mm(W) |
| Film Width | 140-320mm | 140-420mm | 120-520mm | 620mm | 720mm |
| Bag Type | Pillow bag, gusset bag, hole punching bag, vacuum bag,quad seal bag | ||||
| Film Thickness | 0.04-0.09mm | 0.04-0.09mm | 0.04-0.09mm | 0.04-0.09mm | 0.06-0.12mm |
| Film Material | BOPP/CPP, BOPP/VMCPP, BOPP/PE, PET/VMPET, PET/PE | ||||
| Pulling Belt Type | Single/dual belt | Single/dual belt | Synchronous belt film pulling | Synchronous servo motor belt film pulling | Synchronous servo motor belt film pulling |
| Air Consumption | 0.8Mpa 0.25m³/min | 0.8Mpa 0.5m³/min | 0.7Mpa 0.4m³/min | 0.7Mpa 0.5m³/min | 0.7Mpa 0.65m³/min |
| Power Suppply | Single phase 220V 50/60Hz, 2.2kw | Single phase 220V 50/60Hz, 2.2kw | Single phase 220V 50/60Hz, 3.4kw | Single phase 220V 50/60Hz, 4.0kw | Single phase 220V 50/60Hz, 4.5kw |
| Machine Dimension | 1115*800*1370mm | 1530*970*1600mm | 1560*1160*1530mm | 1250*1600*1700mm | 1360*1630*1900mm |
| Machine Weight | 300kg | 450kg | 480kg | 800kg |
900kg |
Company Advantages
· GLZON has been focusing on the design of filling equipment to follow the trend in the market.
· The product is highly valued for its unparalleled quality and practicality.
· Thanks to our unremitting effort in product improvement, this product is able to keep pace with the ever-changing demands of customers and is thought to have a bright future of market application.
Company Features
· Throughout our development history, Shanghai Glzon Equipment Co., Ltd is renowned for abundant experience and expertise in providing high-quality filling equipment.
· Innovation is one of Shanghai Glzon Equipment Co., Ltd's core strengths.
· Our reliable quality of filling equipment will definitely satisfy you. Check it!
Application of the Product
Our filling equipment is widely used in multiple industries and fields.
GLZON has professional engineers and technicians, so we are able to provide one-stop and comprehensive solutions for customers.
